LRAT-3000 LinkRunner AT 3000 Network AutoTester, By NetAlly

LRAT-3000 - LinkRunner AT3000 Network& Cable Tester. By NetAlly

Next Generation Copper and Fiber Ethernet AutoTester

Comprehensive AutoTest validates and troubleshoots all aspects of network linkconnectivity and services.
Verifies available link speed from 10Mbps to 10Gbps, tests PoE, identifies connected switch port and VLAN.
Enables frontline technicians to quickly and thoroughly validate links, troubleshootdevice connectivity, and document moves, adds, and changes.

• Comprehensive AutoTest validates and troubleshoots all aspects of network link connectivity and services including DHCP and DNS.Verifies link speed/duplex for 10/100 Mbps and 1 Gbps, with detection of NBASE-T and Multigigabit 2.5G, 5G, and 10 Gbps links.
• Discovers nearest connected switch name and port information via CDP/LLDP/EDP, including VLANs; monitors VLAN trunk traffic.
• Validates Power over Ethernet switching and cabling up to 90W 802.3bt with TruePower™ loading.
• Advanced twisted-pair cable tests for length, wiremap, and faults such as shorts, opens, mis-wires (split pairs, crossovers), fiber optic link signal strength power measurement and SFP diagnostics. Locate cable endpoints with optional WireView adapters and analog or digital tone generators.
• Use optional USB Wi-Fi/Bluetooth adapter for connectivity and remote control*.
• Automate reporting and enable collaboration with test result uploads, management, and tester remote control via Link-Live™ analysis platform*.

*Active AllyCare Premium Support required for web remote control.

Part code: LRAT-3000.
